Générateur diesel de conteneur

This mobile light tower is powered by reliable Kubota, Yanmar, Perkins, or Quanchai water-cooled 3 or 4-cylinder diesel engines, ensuring dependable performance. Key features include: Powerful Lighting: Equipped with four 400W LED floodlights, delivering a total of 240,000 lumens to provide bright, efficient illumination across large areas. Advanced Digital Control: Features a Smartgen HGM1790N digital controller panel with pre-alarm and shutdown functions, offering alerts for low oil pressure, high temperature, engine overspeed, and generator over/under voltage or overload, ensuring reliable and safe operation. Durable and Resilient: Shock-resistant fixtures are designed to last, providing durability even in tough conditions. Weatherproof and Soundproof Design: Built for outdoor use, the light tower's enclosure offers protection against harsh weather and reduces noise, making it suitable for various environments. Enhanced Stability: Outfitted with one outrigger and four leveling jacks, ensuring stability on uneven terrain and different ground conditions. Sturdy Mechanical Mast: A robust 9-meter mechanical mast with 1,800 lbs self-locking winches provides reliable height adjustment and durability. Flexible and Efficient: Features 359° non-continuous tower rotation and a retractable mast cable, allowing easy positioning for optimal lighting coverage.

Yacht marine generators represent the pinnacle of excellence for professional sailing and boating enthusiasts. Compact, lightweight, and exceptionally quiet, our generators are engineered to deliver unparalleled performance on the open water. Encased within a sound-insulated capsule, they effectively shield against operational noise and vibration, ensuring a serene onboard environment. With seamless installation, our generators operate virtually unnoticed, allowing you to fully enjoy your yachting experience in peace and tranquility.   Standard Configuration √ Water Cooling Exhaust Pipe and Smoke Water Mixer √ Local Contoller and 20M Remote Controller √ 12V Electrical System √ With Heat Exchanger and Rubber Impeller Sea Water Pump

8-hour base fuel tank 50°C radiator with engine-driven cooling fan, mounted on the base frame Set-mounted control panel equipped with DEEPSEA, COMAP, DEIF, or SMARTGEN digital controller Main circuit breaker (MCCB type) from ABB, DELIXI, or CHINT Diesel engine and alternator mounted on a heavy-duty base frame with anti-vibration mounts 24V DC electric starting system with maintenance-free lead-acid batteries and float battery charger Industrial-grade silencer with flexible connection and exhaust elbow Complete engine protection and alarm system

The Hosem Series Engine-Driven Welders are powered by globally recognized brands such as Cummins, Perkins, Deutz, FAW, and Quanchai. They offer welding currents ranging from 250A to 1000A and are equipped with advanced welding technologies, including MMA, GMAW, and TIG. For further information and detailed specifications, please do not hesitate to contact us.

Model GFW11-200AB(E) GFW11-220AB(E) GFW11-250AB(E) GFW11-200AGB(E) GFW11-220AGB(E) GFW11-250AGB(E) Rated Welding Current(A) 200 220 250 200 220 250 Welding voltage(DC)(v) 24-30 24-30 24-32 24-30 24-30 24-32 Welding current range(A) 50-200 50-220 50-250 50-200 50-220 50-250 Applicable ElectrodeΦ(mm) 2.5-4.0 2.5-4.0 2.5-5.0 2.5-4.0 2.5-4.0 2.5-5.0 Duty Cycle  0.6 0.6 0.6 0.6 0.6 0.6 Phase  Single phase/Three phase AC Frequency(Hz) 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz Rated AC Output (KW) 5.0/6.0 6.0/7.0 7.0/7.5 5.0/6.0 6.0/7.0 7.0/7.5 Rated AC Output Voltage(V) 110；120；110/220；120/240；220；230；240；220/380；230/400 Engine Model  GF190F(E) GF192F(E) GF192FB GF190F(E) GF192F(E) GF192FB Max. Outpput (HP) 15 17 18 15 17 18 Displacement (cc) 420 440 460 420 440 460 Type  Single-cylinder,4-stroke,Air cooled,OHV Compression ratio  8.3：1 Starting System  Recoil/Electric           Lubrication Systerm Forced Lubrication           Fuel Tank  (L) 6.5 6.5 6.5 11 11 11 Oil Capacity  (L) 1.1 1.1 1.2 1.1 1.1 1.2 Noise Level (Db/7m) 66 66 70 66 66 70 Packing Dimensions(mm) 810X545X560 810X545X560 810X545X560 810X545X560 810X545X560 810X545X560 Gross Weight(kg) 90 93 107 93 96 110

Assemblage par Perkins tout nouveau moteur et tout nouvel alternateur à palier unique avec IP23, classe H. Options alternateur Marques : Stamford, Leroy Somer, Marathon, Mecc Alte, Hosem, etc. Acier robuste comme plaque de base avec réservoir de carburant de 8 heures de fonctionnement.  Le niveau de bruit extrêmement faible, la verrière est en tôle laminée à froid de 2 mm, remplie de coton silencieux ignifuge de 3 cm d'épaisseur, groupe électrogène complet avec silencieux de type industriel robuste avec soufflet flexible et coude. Amortisseur de vibrations entre moteur/alternateur et châssis de base Disjoncteur tripolaire. Marques de contrôleurs d'options : UK Deepsea, Czech ComAp, CN Smartgen, etc. Fonction de protection complète et fonction d'arrêt d'alarme Conformez-vous à la norme nationale ISO8528 et à la norme de qualité ISO9001.

Assemblage par Cummins tout nouveau moteur et tout nouvel alternateur à palier unique avec IP23, classe H. Options alternateur Marques : Stamford, Leroy Somer, Marathon, Mecc Alte, Hosem, etc. Acier robuste comme plaque de base avec réservoir de carburant de 8 heures de fonctionnement.  Le niveau de bruit extrêmement faible, la verrière est en tôle laminée à froid de 2 mm, remplie de coton silencieux ignifuge de 3 cm d'épaisseur, groupe électrogène complet avec silencieux de type industriel robuste avec soufflet flexible et coude. Amortisseur de vibrations entre moteur/alternateur et châssis de base Disjoncteur tripolaire. Marques de contrôleurs d'options : UK Deepsea, Czech ComAp, CN Smartgen, etc. Fonction de protection complète et fonction d'arrêt d'alarme Conformez-vous à la norme nationale ISO8528 et à la norme de qualité ISO9001.

The Cummins A-C165 is a 150 kVA Three Phase Auto Start 50Hz Silent Diesel Generator featuring the Cummins 6BTAA5.9-G12 engine & Stamford UCI 274 F alternator.    The Cummins 6BTAA5.9-G12 is a robust engine that has been rigorously tested and proven in the market over decades. Its unmatched durability ensures it can withstand any challenging conditions with ease.   Our generators come equipped with an intelligent controller that monitors critical engine and alternator functions. From digital genset metering to comprehensive component protection and utility voltage monitoring, this controller offers a wide range of features. You can also configure time delays for start and stop operations, providing you with precise control over your power supply.   With our extensive global after-sales system, we alleviate your concerns about maintenance and service. No matter where you are, our dedicated support network ensures prompt assistance and peace of mind.
